Curved Pocket Door System Single

See price list below. Call 0333 5770828 to order.

Categories: ,

Description

Create a wow factor with a curved pocket door.

To order please call 0333 5770828.

Use the curved lines of a curve pocket door to soften the division of space in your interior. Our single curved pocket door systems come with the frame, timber lining kit, final architrave and curved door. The doors are available in a variety of real wood veneers.

PRICES & DELIVERY

  • Prices from £4587.28 +VAT. View price list (.pdf).
  • Lead-time from placing order 8-9 weeks.

SIZING

  • Not sure which size you need? Have a look at this SIZE CHART & TECHNICAL SPEC. Still have questions? Call our friendly Customer Services Team on 0333 5770828.
  • Need a non standard size? Call 0333 5770828 for a quote.
  • Need a wider passage width (i.e. opening)?  Have a look at our Double Curved Pocket Door System.

Reviews

There are no reviews yet.

Be the first to review “Curved Pocket Door System Single”

Your email address will not be published. Required fields are marked *

  • Comes complete with door, jambs ,architraves ,dust brushes and recessed door post with integral bumpers. Plasterboard not supplied.
  • Curved door available in a variety of  paint or stain ready real wood veneers including cherry walnut, mahogany, oak, beech, walnut, cherry and wenge. Comes as standard with cherry walnut veneer.
  • The runners are specially constructed to slide in the curved track and adapt to different radii of curvature.
  • The pocket for the curved door is constructed from modular metal sheet.
  • The single curved pocket door system can have a left or right opening action.
  • Sliding system, doors, door jambs and final architraves all supplied.
  • 15 year guarantee on the complete Eclisse steel pocket system.
  • Note: Please specify at time of ordering if doors should be cut for flush pulls. Doors are supplied with cut out for flush pulls as standard.
  • When fitting flush pull handles we recommend the stop be regulated so the door protrudes from the pocket to avoid risk to fingers. Should the door be adjusted to enter the pocket completely we do not accept any liability.
  • TECHNICAL SPEC: Download
  • Bespoke sizing available up to 1200mm x 2600mm with various radii. Call 0333 5770828 for more information.
  • Finished Wall Thickness: 125mm.
  • Use 2 layers of 6mm plasterboard on each side (not supplied).
  • Install at finished floor level.
  • INSTALLATION INSTRUCTIONS: Download | Door Installation
  • CAD drawing (.dwg): See Technical Page.
  • NBS Plus: Download
  • BIM: – Download
